The CSK laboratory offers the entire process chain of injection moulding technology: tool design, mould construction and sampling.



CampusAnsbach
RoomN.N.
Study programmes N.N.
Contact persons N.N.



Laboratory equipment

Production engineering Toolmaking

We manufacture injection moulds for our own needs. This is made possible by our production engineering laboratory, which is geared to the needs of mould making.

  •  Machining
  • CNC Technology
  •  Erosion technology

Equipment

  • Milling machining centre Deckel DMU 50T
  • Turning machining centre Gildemeister CTX310
  • Eroding machine
  • Surface grinding machine Stöckel
  • Workshop

Range of tasks

  • student education
  • Construction of tools for own use



Production technology injection moulding

Equipment

  • Injection moulding machine Demag Ergotech 35-115

Range of tasks

  • student education
  • Injection moulding of parts for own use (test specimens, advertising material, ...)



Tool design and CAD/CAM simulation

We develop and construct in higher education. We use the 3D software Solid Works with the associated mold design module, SolidCAM and MasterCAM.

  • Creation of drawings and 3D models for CNC machining
  • Transfer of 3D data records from other systems (ProE, Catia) via data interface (IGES, VDAFS, Step, ...)
  • Integration of standards from online catalogues

Equipment

  • 15 CAD workstations
  • 3D CAD system Solid Works
  • Current peripherals like network, A0 plotter, native and neutral data interfaces
  • Modern structure software SolidWorks-Simulation for the constructive optimization of components
  • Moldflow software (MPA, MPI, MPX) for the modern design of plastic injection molds
  • SolidCAM and MasterCAM to create programs for machining parts



Range of tasks

  • Student education
  • Technology Transfer
